In stock
Server Chassis
CHS-SRV-K340LC
K340LC 3U Rackmount LCD Industrial Chassis
Product formEmpty chassis
FamilyPanel PC / Display Chassis
Dimension482(W) × 400(D) × 133(H) mm
MountingRackmount
MotherboardATX
Drive Bays8 bays
K340LC 3U 19-inch rackmount industrial chassis with integrated front touchscreen and touch-pad keyboard. The supplier lists SGCC construction, ATX motherboard support up to 305 × 245 mm, ATX PSU support, eight 3.5-inch HDD bays, four PCIe slots with 200 mm length limitation, one 12025 cooling fan, and an 8.9-inch 1024 × 600 display. Supplier-listed dimensions are 482(W) × 400(D) × 133(H) mm.
Specifications
Identity
| Model Number | CHS-SRV-K340LC |
| Product Type | Server Chassis |
Configuration and Use
| Included Components | Empty 3U rackmount chassis with integrated 8.9-inch touchscreen LCD, touch-pad keyboard, and one 120 mm cooling fan. ATX PSU support is provided; PSU and motherboard are not included. |
| Use Case / Application | Industrial PC, Panel PC, Server |
Mounting and Enclosure
| Mounting Orientation | Horizontal |
| Rack Width | 19-inch |
| Rack Height | 3U |
| Material | SGCC steel |
| Width | 482 mm |
| Height | 133 mm |
| Depth | 400 mm |
| Weight | 8.5 kg gross |
Motherboard and Processor
| Maximum Motherboard Dimensions | 305 × 245 mm |
Power Supply
| PSU Support | ATX PSU |
| PSU Included | No |
Storage and Hot-swap
| 3.5-inch Drive Bays | 8 bays |
| 2.5-inch Drive Bays | 0 bays |
| Drive Types | 3.5-inch HDD |
| Hot-swap Support | No |
| Hot-swap Bay Count | 0 bays |
PCIe and GPU Support
| PCIe Slots | 4 slots |
| PCIe Slot Types | PCIe expansion slots, card length up to 200 mm |
Cooling and Thermal
| Included Fan Count | 1 fans |
| Fan Size | 120 × 120 × 25 mm (12025) × 1 |
Display and LCD
| LCD / Display Included | Yes |
| LCD Size | 8.9 in |
| LCD Resolution | 1024 × 600 |
| Touchscreen Support | Yes |
| Touch Technology | Touchscreen |
| Display Position | Front panel |
I/O and Connectivity
| Front I/O | 8.9-inch touchscreen LCD, Touch-pad keyboard |
| Custom I/O Details | Supplier lists an integrated 8.9-inch 1024 × 600 touch display with touch-pad keyboard, eight 3.5-inch HDD positions, four PCIe slots limited to 200 mm card length, one 12025 fan, ATX PSU support, and 305 × 245 mm ATX motherboard support. |
