Made to order
CPU Cooling
SRV-AMD AM4-4UR22
CoolServer AM4 AM5 R22 4U Active CPU Cooler Thermal Simulation Customizable PWM 4-Pin Heatsink Cooling Computer Cases TDP 200W
CPU PlatformAM4, AM5
Power InterfacePWM
Noise40 dBA
Power (TDP)200 W
Air Volume61.46 CFM
CoolServer AM4 AM5 R22 4U Active CPU Cooler Thermal Simulation Customizable PWM 4-Pin Heatsink Cooling Computer Cases TDP 200W. Supplier detail-page values captured from Alibaba.
Specifications
Identity
| Model Number | SRV-AMD AM4-4UR22 |
| Short Description | CoolServer AM4 AM5 R22 4U Active CPU Cooler Thermal Simulation Customizable PWM 4-Pin Heatsink Cooling Computer Cases TDP 200W |
| Description | CoolServer AM4 AM5 R22 4U Active CPU Cooler Thermal Simulation Customizable PWM 4-Pin Heatsink Cooling Computer Cases TDP 200W. Supplier detail-page values captured from Alibaba. |
CPU Compatibility
| CPU Manufacturer | AMD |
| CPU Generation / Platform | AMD-AM4 |
Thermal and Mechanical
| Heat Pipe Count | 5 |
| Heatsink Material | Copper & Aluminum |
| Cooler Dimensions | 98.8 × 100 × 124.8 mm |
| Weight | 0.711 kg |
Fan
| Cooler Type | Active air |
| Fan Included | Yes |
| Fan Dimensions | 92x92x25mm |
| Fan Speed | PWM 1900-3800RPM |
| Connector | 4pin |
| Bearing Type | TWO BALL BEARING |
| Operating Voltage | 12V |
| Fan Life | 50000 Hrs hours |
