Made to order
CPU Cooling
SRV-115X-2UV15
COOLSERVER 115X/1200 Thin Heat Sink Silent Processor Radiator Air Cooling 4Pin Pure Copper Aluminum for Computer Computer Case
CPU PlatformLGA115X, LGA1200
Power Interface4-Pin PWM
Noise52.5 dBA
Power (TDP)200 W
Air Volume47.2 CFM
2U LGA115X/1200 server heatsink with 2 heat pipes and 60mm PWM fan.
Specifications
Identity
| Model Number | SRV-115X-2UV15 |
| Short Description | COOLSERVER 115X/1200 Thin Heat Sink Silent Processor Radiator Air Cooling 4Pin Pure Copper Aluminum for Computer Computer Case |
| Description | 2U LGA115X/1200 server heatsink with 2 heat pipes and 60mm PWM fan. |
CPU Compatibility
| CPU Manufacturer | Intel |
| CPU Generation / Platform | Intel LGA115X/1200 |
| Compatible Chassis Height | 2U |
Thermal and Mechanical
| Heat Pipe Count | 2 |
| Heatsink Material | Copper & Aluminum |
| Base Material | VC soaking plate |
| Cooler Dimensions | 91 × 90 × 65.5 mm |
| Weight | 0.492 kg |
Fan
| Cooler Type | Active air |
| Fan Included | Yes |
| Fan Dimensions | 60 × 60 × 25 mm |
| Fan Speed | PWM 2600-8000 RPM |
| Connector | 4-pin |
| Bearing Type | Double ball bearing |
| Operating Voltage | 12V |
| Fan Life | 50000 hours |
